Navasolar Trolley Inverter 1KW / 12VDC 960WH LIFEPO4 SA Outlets

Description

DESCRIPTION:

All-In-One Energy Storage Solar System
May the power be with you

BP1800 Series
HBP 1800 series all-in-one energy storage solution, support 1KW output for different load appliances. It’s based on the original cabinet design, stacked with solar energy storage lithium battery 960wh, and built in battery protection system, fully retain the use of load power in applications of residentail, school, commercail and public utility area.

1000W – Pure Sine Wave Inverter
4000+ Charge Cycle
24/7 UPS Plug & Play Use
2 x USB ports for DC Load

Features higher capacities for greater compatibility with more power-hungry devices, and the latest in USB-C Power Delivery capable of charging larger USB devices like laptops.
Includes pre-installed solar charging optimization module that functions as a maximum power point tracker (MPPT), resulting in up to 40% faster charge times.
With LiFePO4 lithium cells, known for stability and safety, monitored by a state-of-the-art battery management system that prevents overcharge, over-current, and short circuiting.
Built in Multi safety protection that include short circuit, overload and over-temperture and error code reporting

Specifications
Model: NV-BP18-1012

Inverter:
Rated power: 1000W
Output voltage waveform: Pure sine wave
Output voltage regulation: 230Vac 5%
Output frequency: 50Hz / 60Hz ( 0.2Hz)
Peak efficiency: 90%
Nominal DC input voltage: 12Vdc ( 0.3)
Standby Consumption: < 25W PV Input: Max solar power input: 900W PV max charging current: 60A( 3A) Combined charging current: 70A( 4A) Max efficiency: PV array open circuit voltage: 105VDC PV Array MPPT Voltage Range: 15~105V AC Input: AC input voltage: 230Vac 5% Acceptable input voltage range: 90-280VAC Nominal input frequency: 50Hz / 60Hz (Auto detection) Transfer time: 10ms typical (UPS, VDE); 20ms typical (APL) AC Charge: Charging current @ Nominal input voltage: 10/20A ( 4A) Charging Algorithm: 4-step (Li) Output: AC output: 230Vac (Socket x 4pcs) USB (5V 2.4A): DC output x 2pcs USB (12V 1A): DC output x 1pcs Lithium Battery: Energy: 960Wh Nominal voltage:12.8V Battery capacity:75Ah Protection board:100A Standard charging & discharge current: 50A Operation temperature: Charge 0~45 Discharge -10~60 Dimension: Product Size (LxWxH) (mm) 379x254x499 Packing Size (LxWxH) (mm) 495x365x680 Net Weight (kg): 23 Gross Weight (kg): 32.8
